Distribution boxes



Junction/Surge Box (1 Inlet/ 3 Outlet, 28" x 16" x 14.5"(JB/SB)

PDF | CAD



6-Hole Distribution Box - Small Style (1 Inlet/ 5 Outlet, 16" x 11" x 10"(6DB-SM)



6-Hole Distribution Box (1 Inlet/ 5 Outlet, 24" x 12.5" x 14"(6DB)
PDF | CAD



6-Hole Distribution Box, Side Inlet (1 Inlet/ 5 Outlet, 28" x 15" x 14"(6DB-SIDE)



8-Hole Distribution Box (1 Inlet/ 7 Outlet, 28.5" x 12" x 14"(8DB)
PDF | CAD



8-Hole Distribution Box - Large Style (1 Inlet/ 7 Outlet, 28" x 16" x 12.15"(8DB-LG)
PDF | CAD



8-Hole Distribution Box with Dosing Mid-wall (1 Inlet/ 7 Outlet, 28" x 15" x 14"(8DB-BAF)



10-Hole Distribution Box (1 Inlet/ 9 Outlet, 32" x 13" x 15"(10DB)
PDF | CAD



12-Hole Distribution Box (1 Inlet/ 11 Outlet, 38" x 11" x 13"(12DB)
PDF | CAD



15-Hole Distribution Box (1 Inlet/ 14 Outlet, 52" x 18" x 18"(15DB)
PDF | CAD


Distribution Box Lids

6-Hole Distribution Box Lid (Small) (16" x 11") (6DB-SM-LID)

6-Hole Distribution Box Lid (24" x 12") (6DB-LID)

8-Hole Distribution Box Lid (28" x 12") (8DB-LID)

8-Hole Distribution Box Lid (Large) (28" x 16") (8DB-LG-LID)

10-Hole Distribution Box Lid (32" x 12") (10DB-LID)

12-Hole Distribution Box Lid (35" x 11") (12DB)

15-Hole Distribution Box Lid (52" x 18") (15DB)


DISTRIBUTION BOX ACCESSORIES



Tuf-Tite® 4" Speed Leveler (SL-4)
PDF



Tuf-Tite® 4" Speed Leveler, European Style (SL-4W)
PDF



Tuf-Tite® 3" Speed Leveler (SL-3)
PDF



American Manufacturing 4" Bull Run Valve Kit (BULLRUN-KIT)
